Dimensions
46 x 33.5 x 10.8 mm
Wrist Size
Active Edition
130–210 mm
Classic Edition
140–210 mm
Elegant Edition
120-200 mm
Speaker
Supported
Microphone
Supported
Weight
Active Edition
Approximately 26 g (strap excluded)
Classic Edition
Approximately 30 g (strap excluded)
Elegant Edition
Approximately 30 g (strap excluded)
Display
Size
1.74 inches AMOLED colour screen
Resolution
336 x 480 pixels, PPI 336
Sensors
9-axis IMU sensor (Accelerometer sensor, Gyroscope sensor,Geomagnetic sensor)
Optical heart rate sensor
Button
Full screen touch, side button
Water Resistance
5ATM water-resistant
Environment
Ambient Operating Temperature
-10 ℃ – +45 ℃
Watch Case
Active Edition
Material
Front case: polymer
Rear case: polymer
Classic Edition
Material
Front case: aluminium
Rear case: polymer
Elegant Edition
Material
Front case: aluminium
Rear case: polymer
Watch Strap
Active Edition
Midnight Black Silicone Strap
Sakura Pink Silicone Strap
Isle Blue Silicone Strap
Classic Edition
Nebula Grey Leather Strap
Moon White Leather Strap
Elegant Edition
Premium Gold Milanese Strap
Silver Frost Milanese Strap
Connectivity
Active Edition
NFC
Not Supported
Bluetooth
2.4 GHz, supports BT5.2 and BR+BLE
Classic Edition
NFC
Not Supported
Bluetooth
2.4 GHz, supports BT5.2 and BR+BLE
Elegant Edition
NFC
Not Supported
Bluetooth
2.4 GHz, supports BT5.2 and BR+BLE
System Requirements
Android 6.0 or later
iOS 9.0 or later
Battery Life
Typical usage: 10 days
Default settings are used, 30 minutes of Bluetooth calling per week, 30 minutes of audio playback per week, heart rate monitoring and sleep tracking are enabled, 30 minutes of exercise per week, message notification is enabled (50 SMS messages, 6 calls, and 3 alarms per day), and the screen is turned on 200 times per day.
Heavy usage: 7 days
Default settings are used, 30 minutes of Bluetooth calling per week, 30 minutes of audio playback per week, heart rate monitoring and HUAWEI TruSleep™ are enabled, 60 minutes of exercise per week, message notification is enabled (50 SMS messages, 6 calls, and 3 alarms per day), and the screen is turned on 500 times per day.
*Based on results from HUAWEI lab tests. The actual usage may vary depending on product differences, user habits, and environment variables.
Charging Port
Magnetic charging thimble
Charging
Charger Voltage and Current Requirements
5V/1A
