Image Sensor
Type
Approx. 22.3 × 14.9 mm (APS-C) CMOS
Effective Pixels
24.2MP
Total Pixels
25.5MP
Aspect Ratio
3:2
Low-Pass Filter
Built-in/Fixed
Sensor Cleaning
EOS integrated cleaning system
Colour Filter Type
Primary Colour
Sensor Shift-IS
No
Image Processor
Type
DIGIC X
Lens
Lens Mount
RF (natively supporting RF and RF-S lenses)
EF and EF-S lenses can be attached using Mount Adapter EF-EOS R, EF-EOS R Control Ring Mount Adapter, Drop-in Filter Mount Adapter EF-EOS R
EF-M lenses are not compatible8
Focal Length
Equivalent to 1.6x the focal length of the lens with RF/RF-S and EF/EF-S lenses
Image Stabilisation
Lens/Digital only
Focusing
Type
Dual Pixel CMOS AF II
AF System / Points
With Area 100% horizontal and 100% vertical (Auto selection)
90% horizontal and 100% vertical (Manual selection)9
AF Working Range
EV -4 – 20 (at 23°C & ISO100)2
AF Modes
One Shot
Servo AF
Auto Switch (only in A+ mode)
AF Point Selection
Automatic selection: 651 Available AF areas when automatically selected
Manual selection: 1-point AF (AF frame size can be changed) 4503 AF positions available stills (3713 Movies)
Manual selection: AF point Expansion 4 points (up, down, left, right)
Manual selection: AF point Expansion surrounding
Manual selection: Flexible Zone AF 1-3 (all AF points divided into minimum 9 to 513 maximum focusing zones)
Manual selection: Whole Area AF (Entire focusing area with 651 maximum focusing zones)
AF Tracking
Humans (Eyes/Face/Head/Body), Animals (Dogs, Cats and Birds) or Vehicles (Racing cars or Motor bikes)
AF Lock
Locked when shutter button is pressed halfway or AF ON is pressed in One Shot AF mode. Using customised button set to AF stop in AI servo
AF Assist Beam
Emitted by built in LED or optional dedicated Speedlite (flash)
Manual Focus
Selected on lens/camera10
Exposure Control
Metering Modes
Real-time with image sensor, 384-zone metering.
(1) Evaluative metering (linked to All AF points)
(2) Partial metering (Approx. 5.8% of viewfinder at centre)
(3) Spot metering: Centre spot metering (Approx. 2.9% viewfinder at centre) AF point-linked spot metering not provided
(4) Centre weighted average metering
Metering Brightness Range
EV -2 – 20 (at 23°C, ISO100, with evaluative metering)
AE Lock
Auto: AE lock takes effect when focus is achieved (AE is locked as soon as subjects are in focus using One-Shot AF when set to [C.Fn 2: AE lock meter. mode after focus].)
Manual: By AE lock button in P, Av, Fv, Tv and M modes
Exposure Compensation
+/-3 EV in 1/3 or 1/2 stop increments (can be combined with AEB)
AEB
+/-3 EV in 1/3 or 1/2 stop increments
Anti-flicker Shooting
Yes. Flicker detected at a frequency of 100 Hz or 120 Hz.11
ISO SensitivityOpen
Auto 100-32000 (in 1/3-stop or whole stop increments)
ISO can be expanded to H: 5120012
Shutter
Type
Electronically controlled focal-plane shutter and Electronic shutter function in sensor
Speed
Mechanical: 30-1/4000 sec (1/2 or 1/3 stop increments), Bulb, Electronic: 30-1/16000 (1/2 or 1/3 stop increments up to 1/8000 then 1 stop until 1/16000) (Total shutter speed range. Available range varies by shooting mode)
Shutter Release
Soft-touch electromagnetic release
White Balance
Type
Auto white balance with the imaging sensor
AWB (Ambience priority/White priority), Daylight, Shade, Cloudy, Tungsten light, White Fluorescent light, Flash, Custom, Colour Temperature Setting"
Settings
White balance compensation:
1. Blue/Amber +/-9
2. Magenta/Green +/-9
Custom White Balance
Yes, 5 setting can be registered
+/-3 levels in single level increments
WB Bracketing
3, 2, 5 or 7 bracketed images per shutter release
Selectable Blue/Amber bias or Magenta/Green bias
Viewfinder
Type
0.39 inch OLED colour EVF
Dot Count
2.36 Million dots (1024x768)
Coverage (Vertical/Horizontal)
Approx. 100%
Magnification
Approx. 0.95x13
Eyepoint
Approx. 22mm (At -1 m-1 from eyepiece lens end)
Dioptre Correction
-3 to +1 m-1 (dioptre)
Display Performance
Power saving: 59.94 fps Smooth 119.98 fps4
Viewfinder Information
Accessory attached indicator, AE lock, AEB, AF area, AF method, AF operation, AF point (1-point AF), AF point information, Anti-flicker shooting, Aperture value, Aspect ratio, Audio recording level (manual), Audio recording level indicator (manual), Auto Lighting Optimizer, Battery level, Bluetooth function, Canon Log, Card for recording/playback, Creative filters, Bulb timer, Digital Lens Optimizer, Digital zoom, Drive mode, Electronic level, Electronic shutter, Exposure compensation, Exposure level indicator, Exposure simulation, FE lock, FEB, Flash off, Flash-ready, Focus bracketing, focus distance scale, GPS, Grid, HDR PQ, HDR shooting, Headphone volume, Highlight tone priority, High-speed sync, Histogram (Brightness/RGB), Image Quality, Image Stabilizer (IS mode), Interval timer, ISO speed, Lens information, Magnify button, Maximum burst, Metering mode, Movie recording in progress, Movie recording size, Movie recording time available, Movie recording time available/Elapsed recording time, Movie self-timer, Movie Servo AF, Multi Shot Noise Reduction, Multi Shot Noise Reduction, Multi-function lock warning, Multiple-exposure shooting, No. of remaining shots for focus bracketing, Number of available shots/Sec. until self-timer shoots, Number of remaining multiple exposures, Number of self-timer shooting, Overheat control, Picture Style, Quick Control button, Shooting mode, Shutter speed, Still photo cropping, Subject to detect, Touch Shutter/Create folder, vertical exposure scale, View Assist, White balance, White balance correction, Wi-Fi function, Wi-Fi signal strength
Depth of Field Preview
Yes, via customised button
LCD Monitor
Type
7.5 cm (2.95") TFT colour LCD monitor, Approx. 1.04 million dots
Coverage
Approx. 100%
Viewing Angle (Horizontally/Vertically)
Approx. 150° vertically and horizontally
Coating
Anti-smudge.
Brightness Adjustment
Manual: Adjustable to one of seven levels
Colour Tone Adjustment: 4 settings
Touch Screen Operations
Capacitive method with menu functions, Quick Control settings, playback operations, and magnified display. AF point selection in still and Movies, touch shutter is possible in still photo shooting.
Display Options
(1) Basic Camera settings
(2) Advance Camera settings
(3) Camera settings plus histogram and dual level display
(4) No info
(5) Quick Control Screen
(6) Display off
Flash
Built-in Flash GN (ISO 100, meters)
6
Built-in Flash Coverage
Approx. 18 mm focal length/angle of view (35mm equivalent: approx. 29 mm)
Built-in Flash Recycle Time
Approx. 5 sec.
Modes
E-TTL II Auto Flash, Metered Manual
Red-Eye Reduction
Supported
X-Sync
1/200 sec. mechanical shutter
1/250 sec. electronic 1st curtain
Flash photography is not available with Electronic shutter.
Flash Exposure Compensation
+/- 3EV in 1/3 increments with EX series Speedlite flashes
Flash Exposure Bracketing
Yes, with compatible External Flash (+/- 3EV in 1/3- or 1/2-stop increments with EX/EL series Speedlite flashes)
Flash Exposure Lock
Yes
Second Curtain Synchronisation
Yes, (With both the built-in and external Speedlites)
HotShoe / PC Terminal
Yes/No
External Flash Compatibility
E-TTL II with EX/EL series Speedlite, wireless multi-flash support
External Flash Control
via camera menu screen
Shooting
Modes
Stills: Scene Inteligent Auto, 15 Special Scene modes(including Panning/Panoramic Shot), Creative Filters, Flexible priority AE, Program AE, Shutter priority AE, Aperture priority AE, Manual, Bulb and Custom (x2)
Movie: HDR Movies, Movie Auto Exposure, Movie Manual Exposure
Picture Styles
Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3)
Colour Space
"sRGB and Adobe RGB / Fixed at HDR PQ Highlight Tone Priority (3 settings) Auto Lighting Optimizer (4 settings)
Long exposure noise reduction (3 settings)
High ISO speed noise reduction (4 settings) (still and video)
Clarity (+/- 4)
Lens optical correction:
- Peripheral illumination correction, Chromatic aberration correction, Distortion correction (during/after still photo shooting, during video only)
- Diffraction correction, Digital Lens Optimizer (during/after still photo shooting)"
Image Processing
Resize JPEG / HEIF images to M, S1, S2
Cropping: JPEG / HEIF images can be cropped (Aspect ratios 3:2, 4:3, 16:9, 1:1)
Cropping of images
- Switch between vertical and horizontal cropping orientation
- Image straightening
- Cropping frame can be moved using touch screen operation
RAW image processing
Cloud RAW image processing
Multiple exposure
HDR
HEIF to Jpeg conversion
Drive Modes
Single, Continuous High+, Continuous High, Continuous Low, Self-timer (2s+remote, 10s+remote, continous)
Continuous Shooting
Max. Approx. 15 FPS1 with Mechanical shutter/1st curtain electronic shutter the speed maintained for 460 JPEG or 29 RAW images14
Max. Approx. 23 FPS with Electronic shutter5 the speed maintained for 70 JPEG or 21 RAW images14
Interval Timer
Built in
File Type
Still Image Type
RAW 14 bit: RAW and C-RAW (Canon original RAW 3rd edition)
JPEG 8 bit: 2 compression options
HEIF 10 bit: 2 compression options
Complies with Exif 2.31 and Design rule for Camera File system 2.0
Complies with Digital Print Order Format [DPOF] Version 1.1
RAW+JPEG Simultaneous Recording
Yes, any combination of RAW + JPEG or RAW + HEIF possible
Image Size
RAW / C-RAW:
3:2 ratio 6000x4000
JPEG/ HEIF:
3:2 ratio (L) 6000x4000, (M) 3984x2656, (S1) 2976x1984, (S2) 2400x1600
4:3 ratio (L) 5328x4000, (M) 3552x2664, (S1) 2656x1992, (S2) 2112x1600
16:9 ratio (L) 6000x3368, (M) 3984x2240, (S1) 2976x1680, (S2) 2400x1344
1:1 ratio (L) 4000x4000, (M) 2656x2656, (S1) 1984x1984, (S2) 1600x1600
Folders
New folders can be manually created and selected
File Numbering
(1) Continouos numbering
(2) Auto reset
(3) Manual reset
File Naming
N/A
EOS Movie
Movie Type
MP4 Video:
4K UHD, Full HD (16:9)
4K / Full HD: H.265 / HEVC, Audio: AAC / Linear PCM
4K / Full HD: H.264 / MPEG-4 AVC, Audio: AAC / Linear PCM
Movie Size
4K UHD Fine (16:9) 3840 x 2160 (29.97, 25, 23.98 fps) inter frame / light inter frame15
4K UHD Crop (16:9) 3840 x 2160 (59.94, 50 fps) inter frame / light inter frame
4K / Full HD Time-lapse (16:9) 3840 x 2160 / 1920 x 1080 (29.97, 25 fps) intra frame16
Full HD (16:9) 1920 x 1080 (119.9, 100, 59.94, 50, 29.97, 25, 23.98 fps) inter frame / light inter frame17
Full HD (16:9) 1920 x 1080 HDR (29.97, 25 fps) inter frame18
Colour Sampling (Internal Recording)
4K UHD / Full HD - YCbCr4:2:0 8-bit or YCbCr4:2:2 10bit (when HDR PQ is enabled)
Canon Log
Not supported
Movie Length
Max duration 2 hours (excluding High Frame Rate movies). No 4 GB file limit with exFAT formatted card.19
High Frame Rate Movie
Full HD 1920 x 1080 at 100 fps or 119.9 fps
Recorded as 1/4-speed slow motion movie20
Frame Grab
8.3-megapixel JPEG still image frame grab from 4K UHD movie possible21
(HEIF only possible when HDR PQ is set)
Bitrate / Mbps
MOV: MP4 HDR PQ: Off:
4K UHD (29.97p/25.00p/23.98p): IPB Approx. 120 Mbps
4K UHD (29.97p/25.00p/23.98p): IPB Light Approx. 60 Mbps
4K UHD (crop) (59.94p/50.00p): IPB Approx. 230 Mbps
4K UHD (crop) (59.94p/50.00p): IPB Light Approx. 120 Mbps
4K UHD Time-lapse (29.97p/25.00p): ALL-I Approx. 470 Mbps
Full HD (119.9p / 100p): IPB Approx. 120 Mbps
Full HD (119.9p / 100p): IPB Light Approx. 70 Mbps
Full HD (59.94p/50.00p): IPB Approx. 60 Mbps
Full HD (59.94p/50.00p): IPB light Approx. 35 Mbps
Full HD (29.97p/25.00p/23.98p): IPB Approx. 30 Mbps
Full HD (29.97p/25.00p/23.98p): IPB Light Approx. 12 Mbps
Full HD Time-lapse (29.97p/25.00p):ALL-I Approx. 90 Mbps
MOV: MP4 HDR PQ: On
4K UHD (29.97p/25.00p/23.98p): IPB Approx. 170 Mbps
4K UHD (29.97p/25.00p/23.98p): IPB Light Approx. 85 Mbps
4K UHD (crop) (59.94p/50.00p): IPB Approx. 340 Mbps
4K UHD (crop) (59.94p/50.00p): IPB Light Approx. 170 Mbps
4K UHD Time-lapse (29.97p/25.00p): ALL-I Approx. 470 Mbps
Full HD (119.9p / 100p): IPB Approx. 180 Mbps
Full HD (119.9p / 100p): IPB Light Approx. 100 Mbps
Full HD (59.94p/50.00p): IPB Approx. 90 Mbps
Full HD (59.94p/50.00p): IPB light Approx. 50 Mbps
Full HD (29.97p/25.00p/23.98p): IPB Approx. 45 Mbps
Full HD (29.97p/25.00p/23.98p): IPB Light Approx. 28 Mbps
Full HD Time-lapse (29.97p/25.00p):ALL-I Approx. 135 Mbps
Dual Card Recording
No
Microphone
Built-in stereo microphone (48 KHz, 16-bit x 2 channels)
HDMI Display
Output to external monitor only (output of images and shooting information, images/video are recorded to the card)
Camera screen and External Monitor output (Recording to camera is not possible, use with external recorder, camera screen shows images with shooting information)
HDMI Output
Auto:
- 4K (UHD) 59.94p / 50.00p/29.97p /25.00p/23.98p,
- 1080 59.94p / 59.94i, 50.00p / 50.00i
- 480 59.94p
- 576 50p
1080p:
- 1080 59.94p / 59.94i, 50.00p / 50.00i
- 480 59.94p
- 576 50p
Uncompressed YCbCr 4:2:0, 8-bit or when HDR PQ is enabled YCbCr 4:2:2, 10-bit, sound output via HDMI is also possible
Focusing
Dual Pixel CMOS AF II with Eye/Face Detection and Tracking AF (people, animals and vechiles), Movie Servo AF, Manual Focus
ISO
Auto: 100-12800, H: 25600
Manual: 100-12800, H: 16000-25600
Other Features
Custom Functions
18 custom functions + button and dial customisations
Metadata Tag
User copyright information (can be set in camera)
LCD Panel / Illumination
No
Water/Dust Resistance
No
Voice Memo
No
Intelligent Orientation Sensor
Yes
Playback Zoom
1.5x - 10x in 15 steps
Display Formats
(1) Single image
(2) Single image with information (2 levels)
Basic - Shooting information (shutter speed, aperture, ISO and Image quality)
Detailed - Shooting information (shutter speed, aperture, ISO, metering Image, quality and file size), Lens information, Brightness and RGB histogram, White balance, Picture Style, Color space and noise reduction, Lens optical correction, GPS information
(3) 4 image index
(4) 9 image index
(5) 36 image index
(6) 100 image index
(7) Jump Display (1, 10 or Custom(30) images, start of burst sequence Date, Folder, Movies, Stills, Protected images, Rating)
(8) Movie edit
(9) RAW processing
(10) Rating
SlideShow
Image selection: All images, by Date, by Folder, Movies, Stills, Protected images or Rating
Playback time: 1/2/3/5/10 or 20 seconds
Repeat: On/Off
Histogram
Brightness: Yes
RGB: Yes
Highlight Alert
Yes
Image Erase
Single image, select range, Selected images, Folder, Card
Image Erase Protection
Erase protection of Single image, Folder or Card all found images (only during image search)
Self Timer
2 or 10 sec.
Menu Categories
(1) Shooting menu
(2) AF Menu
(3) Playback menu
(4) Network
(5) Setup menu
(6) Custom Functions menu
(7) My Menu
Menu Languages
29 Languages
English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Vietnamese, Hindi, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean, Malay, Indonesia and Japanese
Firmware Update
Update possible by the user (Camera, Lens, External Speedlite, BLE remote control, Lens adapter, multi-function shoe accessories)
Interface
Computer
Hi-Speed USB 2.0 USB Type-C connector also used for computer communication / smartphone communication / USB power.
Wi-Fi
Wireless LAN (IEEE802.11b/g/n) (2.4 GHz), with Bluetooth 4.2 support Features supported - EOS Utility, Smartphone, Upload to image.canon, Wireless printing
Other
HDMI Micro out (Type D, HDMI-CEC not supported)
External Microphone In (3.5mm Stereo mini jack)
RS-60E3-type terminal (remote control terminal)
Direct Print
Canon Printers
Canon Compact Photo Printers and PIXMA Printers supporting PictBridge via wireless LAN
PictBridge
Yes (via Wireless LAN)
Storage
Type
SD/SDHC/SDXC and UHS-II22
Supported Operating System
PC
Windows 10 and Windows 11 (tablet mode not supported)
Macintosh
OS X v10.14, 10.15. OS 11
Software
Image Processing
Digital Photo Professional 4.16.10 or later
Digital Photo Professional Express mobile app (iOS only)
Other
EOS Utility 3 (incl. Remote Capture), Picture Style Editor, EOS Lens Registration Tool, Canon Camera connect app (iOS/Android)
Power Source
Batteries
Rechargeable Li-ion Battery LP-E17 (supplied)23
Battery Life
With LCD Approx. 430 shots (at 23°C)24
With Viewfinder Approx. 260 shots (at 23°C)24
Battery Indicator
4 level indicator
Power Saving
Screen dimmer: 5 sec. / 10 sec. / 15 sec. / 20 sec. /25 sec. / 30 sec. / Disable
Screen off: 5 sec. / 15 sec. / 30 sec. / 1 min. / 3 min. / 5 min. / 10 min. / 30 min. / Disable
Auto power off: 15 sec. / 30 sec. / 1 min. / 3 min. / 5 min. / 10 min. / 30 min. / Disable25
Viewfinder off: 1 min. / 3 min. / Disable
Power Supply & Battery Chargers
Battery charger LC-E17E (supplied), AC Adapter AC-E6N and DC Coupler DR-E18, PD-E1 USB power adapter23
Accessories
Wireless File Transmitter
None
Cases / Straps
An included strap, Hand Strap E2
Lenses
All RF and RF-S lenses (EF & EF-S via Lens adapters)
Lens Adapters
Mount Adapter EF-EOS R, EF-EOS R Control Ring Mount Adapter, Drop-in Filter Mount Adapter EF-EOS R
Flash
Canon Speedlite (EL-1*, EL-5, EL-100, 90EX, 220EX, 270EX, 270EX II, 320EX, 380EX, 420EX, 430EX, 430EX II, 430EX III 470EX-AI, 550EX, 580EX*, 580EX II*, 600EX*, 600EX-RT*, 600EX-II-RT*, Macro-Ring-Lite MR-14EX, Macro Ring Lite MR-14EX II, Macro Twin Lite MT-24EX, Macro Twin Lite MT-26EX-RT, Speedlite Transmitter ST-E2, Speedlite Transmitter ST-E3-RT*, Speedlite Transmitter ST-E3-RT V2*, Speedlite Transmitter ST- E10, Off-Camera Shoe Cord OC-E3*)
*Must use Multi-Function Shoe Adapter AD- E1 to retain weather sealing
Remote Controller / Switch
RS-60E3-type terminal (remote control terminal), Timer Remote Controller TC-80N326, Wireless Remote Control BR-E1, Infrared Remote Controller RC-6, Smartphone(Using Canon Camera Connect app)
Other
Shoe cover ER-SC2 (Included), Multi-Function Shoe Adapter AD-E1, Multi-Function Shoe Directional Stereo Microphone DM-E1D, Multi-Function Shoe Adapter for Smartphone Link AD-P1 for Android, Stereo Microphone DM-E1 / DM-E100, GPS Receiver GP-E227, Tripod grip HG-100TBR28, Interface Cable IFC-100U, Interface Cable IFC-400U, Protecting Cloth PC-E1 / E2,
Physical Specifications
Body Materials
Primarily consists of a magnesium alloy and high-strength engineering plastic
Operating Environment
0 – 40 °C, 85% or less humidity
Dimensions (W x H x D)
Approx. 122.5 x 87.8 x 83.4mm
Weight (Body Only)
Approx. 382 g (429g with card and battery, Based on CIPA guidelines.)
